I cannot find these two devices:

  • Neutral Earthing (Grounding) Resistor
  • Transformer with 3 windings; therefore needing at least 3 terminals:
  1. 110kV IN
  2. 33kV OUT
  3. 11kV OUT
  4. neutral connection(s)


Any ideas would be helpful.

Reply
0 Kudos
2 Replies
Occasional Contributor




Reply
0 Kudos
by
Occasional Contributor

Hi,

The Esri provided electric asset package it's a starting point, if you don't find an element that you want to model in your project you can add your own asset groups/asset types to suit your needs.
