Trace Network Function Barrier - Include Barrier Feature

83
0
07-29-2021 12:40 PM
AlexVerville
New Contributor II

Hello,

I have made a trace network and am trying to select all sewers that are 200m downstream of the starting point. I have created a function barrier that stops the trace when the length of pipe traced is greater than 200m. The issue I am having is that it is not selecting pipes that start before 200m but end after 200m. For example, if it has traced 190m, it will not include the next pipe if it is >10m long since that would bring the traced distance over 200m. Does anybody have a solution for this?

I am using ArcGIS Pro 2.8.1 and have included a screenshot of my Trace tool for reference. Let me know if you need anymore information.


Thanks
