How do I combine two lines of a polygon's table?

803
4
Jump to solution
03-13-2024 09:54 PM
VincentBelanger
Emerging Contributor

It is probably an easy newbie question:
How do I combine two lines of a shapefile polygon's table?

In this exemple, I want to combine the lines with the FIDs 2 and 3 togheter (the two selected ones)
How do I do that?




2 Solutions

Accepted Solutions
Dale_Honeycutt
Frequent Contributor

Take a look at the geoprocessing Dissolve tool.  Dissolve creates a new feature class by merging together adjacent polygons (polygons that share a border) that have the same attribute.  In your case, it looks like you'd dissolve on the md_tempora field.  In your example above, it would merge the 3 polygons that make up the lake (I notice you have 2 polygons selected, but it looks like 3 polygons make the lake)

View solution in original post

RichardHowe
Frequent Contributor

Editor toolbar. Start an edit session. Highlight the two polygons (as you have in your screenshot) and choose "merge" from the editor dropdown menu, then pick the record containing the set of attributes you wish to keep

View solution in original post

4 Replies
VincentBelanger
Emerging Contributor

I forgot to indicate that I am trying to make them "one" object and that I'm on ArcMap!

0 Kudos
Dale_Honeycutt
Frequent Contributor

Take a look at the geoprocessing Dissolve tool.  Dissolve creates a new feature class by merging together adjacent polygons (polygons that share a border) that have the same attribute.  In your case, it looks like you'd dissolve on the md_tempora field.  In your example above, it would merge the 3 polygons that make up the lake (I notice you have 2 polygons selected, but it looks like 3 polygons make the lake)

RichardHowe
Frequent Contributor

Editor toolbar. Start an edit session. Highlight the two polygons (as you have in your screenshot) and choose "merge" from the editor dropdown menu, then pick the record containing the set of attributes you wish to keep

VincentBelanger
Emerging Contributor

Cool! Thx friend!
